Overview
The TPKX-RJ45-1000 series is designed for Gigabit Ethernet (Cat 6) surge protection. It safeguards Ethernet-connected equipment from transient overvoltages caused by lightning or switching activity. With shielding, fast clamping response, and bi-directional protection, it ensures minimal signal interference and high reliability for industrial, telecom, and IT environments.

Key Features
Interface: RJ45 (shielded)
Network type: Cat 6, 1000 Mbps
Uc: 8 Vdc | Up: ≤ 30 V
Response time: < 10 ns
Discharge capacity: In = 3 kA (8/20 μs)
Protection path: Pins 1–8 (all lines protected)
Mounting: RJ inline or optional DIN rail
Housing: Aluminum | Protection: IP20
Operating temp: –40°C to +80°C
